416 and 417 Touch bar two point locking with horizontal latches

Exidor single point locking touch bar panic latch with a sleek design combined with smooth operation to give a solution ideal for use in front of the house or other public areas.

The unit is operated by pressing the bar into the door face retracting the latch bolt and releasing the bar returning the latch bolt to the rest position. The touch bar is available in two standard sizes to suit doors up to 900mm or 1200mm wide (Bar widths are set sizes with other sizes available on request).

Microswitch, alarm, and holdback dogging options (Suffix order code with “MS” for microswitch, “AL” for alarm, or “WD” for dogging (holdback) – not suitable for fire doors).

Certified in compliance with EN 1125 and suitable for timber doors up to FD120 and FD120/FD240 metal doors.  Indicate the required finish when ordering.

Exidor panic touch bar with two vertical Pullman latches, ideal for sports halls, public access areas, and front-of-house applications. The unit is operated by pressing the bar into the door face retracting the latches and releasing the bar returning the latch bolts to the rest position.

Two standard sizes to suit doors up to 900mm or 1200mm wide (Bar widths are set sizes with other sizes available on request). Microswitch, alarm, and holdback dogging options (Suffix order code with “MS” for microswitch, “AL” for alarm, or “WD” for dogging (holdback) – not suitable for fire doors).

Certified in compliance with EN 1125 and suitable for timber doors up to FD120 and FD120/FD240 metal doors. Indicate the required finish when ordering.

Exidor panic touch bar with central latch and vertical Pullman latches, ideal for sports halls, public access areas, and front-of-house applications.

The unit is operated by pressing the bar into the door face retracting the latches and releasing the bar returning the latch bolts to the rest position.

Two standard sizes to suit doors up to 900mm or 1200mm wide (Bar widths are set sizes with other sizes available on request). Microswitch, alarm, and holdback dogging options (Suffix order code with “MS” for microswitch, “AL” for alarm, or “WD” for dogging (holdback) – not suitable for fire doors).

Certified in compliance with EN 1125 and suitable for timber doors up to FD120 and FD120/FD240 metal doors.  Indicate the required finish when ordering.

Exidor panic touch bar with central latch and vertical Pullman latches, ideal for sports halls, public access areas, and front-of-house applications.

The unit is operated by pressing the bar into the door face retracting the latches and releasing the bar returning the latch bolts to the rest position. Two standard sizes to suit doors up to 900mm or 1200mm wide (Bar widths are set sizes with other sizes available on request).

Microswitch, alarm, and holdback dogging options (Suffix order code with “MS” for microswitch, “AL” for alarm, or “WD” for dogging (holdback) – not suitable for fire doors).

Certified in compliance with EN 1125 and suitable for timber doors up to FD120 and FD120/FD240 metal doors.  Indicate the required finish when ordering.

Exidor touch bar panic mortice actuator with Euro profile cylinder lock, ideal for low traffic doors in public areas such as schools or healthcare premises requiring key entry only.

The unit is operated by pressing the bar into the door face retracting the mortice lock latch and releasing the bar returning the mortice lock latch to the rest position. Two standard sizes to suit doors up to 900mm or 1200mm wide (Bar widths are set sizes with other sizes available on request).

Microswitch and alarm options available (Suffix order code with “MS” for microswitch, “AL” for alarm). Certified in compliance with EN 1125.

Indicate required finish when ordering.
