325 Lever outside access device | UNION

Exidor easy and convenient lever outside access device for use with 200 series and 300 series hardware, for gaining entry through an escape door.

The unit is operated by pushing the lever down to retract the internal bolts/latches, releasing the lever returns the internal bolts/latches to the rest position.

Available with or without a Euro cylinder. Key retention model available (Suffix order code with “RK” for key retention). Locking the cylinder prevents access into the building but will not prevent escape from the building.

Certified as an approved accessory to 200/300 series hardware as part of EN 1125 and EN 179. Indicate the required finish when ordering (plated finishes are not recommended for external use). Additional fixings for thicker doors are available on request.

Brochures (for Webshop/AEM) S3
Lever design is simple and easy to open with hand, fist, elbow
The lever dimensions help to meet the requirements for BS 8300 for a more inclusive building design
Bolt through fixings make it suitable for steel or timber doors up to 65mm thick
Cylinder specification for master keying needs: 45mm single euro profile cylinder, with regular side face drill and tap fixing (Suffix order code with “KA” for keyed alike)
Suitable for use with: 296, 294, 294A, 285, 284, 297, 293, 293A

Name	Value
Brand	UNION
Alarmed	No
Cylinder Detail	Euro
Dogged	N/A
Door Opening	Outward
Door Type	Plain Meeting Stile Double Either Leaf, Rebated Double Active Leaf, Single, Steel, Timber
Fire Door Approval	No
Fire Rated	N/A
Fire Rated Metal	N/A
Fire Rated Timber	N/A
Handing	Universal
Keep Detail	N/A
Locking Points	0
Max Door Height (mm)	2440
Max Door Width (mm)	1220
Micro Switched	N/A
Mounting Method	Surface Mounted
Operator Detail	Lever
Product Subtitle	Introducing The Exidor 325 Lever Outside Access Device – The Perfect Solution For Easy Entry Through Escape Doors. Designed For 200 And 300 Series Hardware, Its Simple Lever Operation Ensures Quick Access. Compatible With Euro Cylinders, It's Ideal For Both Security And Safety. Suitable For Steel Or Timber Doors Up To 65mm Thick.
Projection (mm)	95mm
Standard	CE, EN 1125, EN 179, UKCA

Product	Product ID
325 Lever outside access device	15801000
325 Lever outside access device	15801003
325 Lever outside access device	15801004
325 Lever outside access device	15801030
325 Lever outside access device	15801050
325 Lever outside access device	15801100
325 Lever outside access device	15801150
